Quiz Corner: Coriolis mass flowmeter orientation for gas applications, part 1
Which of the following orientations can be used to install a Coriolis mass flowmeter to measure the mass flow of a gas in a horizontal pipe?
A. U-tube down
B. Inverted U-tube
C: U-tube horizontal (parallel to grade)
Coriolis mass flowmeters in gas service must be completely full of gas to measure accurately. The U-tube down orientation (Answer A) could accumulate liquid and should not be used for gas applications.
Few Coriolis mass flowmeters are mounted in the horizontal plane (Answer C), so mounting the flowmeter with an inverted U-tube orientation (Answer B) that hydraulically removes liquid from the flowmeter would be practical.
Additional complicating factors
Not all Coriolis mass flowmeters have U-tube geometry, and some of these geometries can allow liquid to accumulate in the flowmeter.
For example, a single path self-filling and self-draining Coriolis mass flowmeter that forms a loop, jumps up and then forms another loop must be installed in the horizontal plane (Answer C) to remove all liquid from the system because any other orientation can allow liquid to accumulate in the flowmeter.
